Z Transform: Example Important Solved Problems with formula, steps, derivation and answer based on Z Transform - Initial value theorem and final value theorem.

Initial value theorem and final value theorem.



1. Initial value theorem

If Z [f(n)] = F(z), then f(0) = limz→∞ F(z)

Proof :




2. Final value theorem.

If Z{f(n)} = F(z), then lim n→∞ [f(n)] = limz→1 (z − 1) F(z)

Proof:




Problems based on initial value theorem and final value theorem
